1、Chemical Composition
Grade | N | C | H | Fe | O | Al | V | Pa | Mo | Ni | Ti |
Gr1 | 0.03 | 0.08 | 0.015 | 0.2 | 0.18 | / | / | / | / | / | bal |
Gr2 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | / | / | bal |
Gr3 | 0.05 | 0.08 | 0.015 | 0.3 | 0.35 | / | / | / | / | / | bal |
Gr4 | 0.05 | 0.08 | 0.015 | 0.5 | 0.4 | / | / | / | / | / | |
Gr5 | 0.05 | 0.08 | 0.015 | 0.4 | 0.2 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
Gr7 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
Gr9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | / | / | / | bal |
Gr12 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 | bal |
2、Tensile Requirements
Grade | Tensile strength(min) | Yield Strength(min) | Elongation(%) | ||
ksi | MPa | ksi | MPa | ||
Gr1 | 35 | 240 | 20 | 138 | 24 |
Gr2 | 50 | 345 | 40 | 275 | 20 |
Gr3 | 65 | 450 | 55 | 380 | 18 |
Gr4 | 80 | 550 | 70 | 483 | 15 |
Gr5 | 130 | 895 | 120 | 828 | 10 |
| Product name | Grade | Specifications(mm) | ||||
| Outer diameter | Inner diameter | Section Height | Ring material thickness | Standard | ||
| Titanium Disc | GR1 GR2 GR5 GR7 GR9 GR12 | 150--300 | / | 35-140 | / | ASTM B381 |
| >300--500 | / | 35-150 | / | |||
| >500--600 | / | 40-110 | / | |||
| Titanium Ring | 200--400 | 100-300 | 35-120 | 40-150 | ||
| >400--700 | 150-500 | 40-160 | 40-250 | |||
| >700--900 | 300-700 | 50-180 | 40-300 | |||
| >900--1300 | 400-900 | 70-250 | 40-400 | |||
